Steel Sections (Profiles)
Hollow sections of steel (RHS, SHS and CHS) are available in metric sizes. Hot finished, hollow steel sections are supplied in accordance with EN10210 and cold formed sections EN10219. The capacities of hot finished and cold formed are not the direct equivalents therefore care is required to ensure correct grade is requested despite section dimensions being identical.
Universal Columns (UC)
Studley Special Steels offer a wide range of Universal Columns (UC). In particular, we specialise in high yield steel columns for use in low temperature environments. Low temperature impact testing is available with lengths from 6 metres to 20 metres as standard.
Standards/Grades:
- EN 10025 S275
- EN 10025 S355
Note: The suffix ‘UC’ refers to UK steel columns – for continental columns (also referred to as H Sections) please click here.
Please refer to the sizes/specification table below.
| Metric Dimensions | kg/m | Section Depth mm | Section Width mm | Web Thickness mm | Flange Thickness mm |
|---|---|---|---|---|---|
| 152x152x23 | 23.00 | 152.40 | 152.20 | 5.80 | 6.80 |
| 152x152x30 | 30.00 | 157.60 | 152.90 | 6.50 | 9.40 |
| 152x152x37 | 37.00 | 161.80 | 154.40 | 8.00 | 11.50 |
| 152x152x44 | 44.00 | 166.00 | 155.90 | 9.50 | 13.60 |
| 152x152x51 | 51.20 | 170.20 | 157.40 | 11.00 | 15.70 |
| 203x203x46 | 46.10 | 203.20 | 203.60 | 7.20 | 11.00 |
| 203x203x52 | 52.00 | 206.20 | 204.30 | 7.90 | 12.50 |
| 203x203x60 | 60.00 | 209.60 | 205.80 | 9.40 | 14.20 |
| 203x203x71 | 71.00 | 215.80 | 206.40 | 10.00 | 17.30 |
| 203x203x86 | 86.10 | 222.20 | 209.10 | 12.70 | 20.50 |
| 203x203x100 | 99.60 | 228.60 | 210.30 | 14.50 | 23.70 |
| 203x203x113 | 113.50 | 235.00 | 212.10 | 16.30 | 26.90 |
| 203x203x127 | 127.50 | 241.40 | 213.90 | 18.10 | 30.10 |
| 254x254x73 | 73.10 | 254.10 | 254.60 | 8.60 | 14.20 |
| 254x254x89 | 88.90 | 260.30 | 256.30 | 10.30 | 17.30 |
| 254x254x107 | 107.10 | 266.70 | 258.80 | 12.80 | 20.50 |
| 254x254x132 | 132.00 | 276.30 | 261.30 | 15.30 | 25.30 |
| 254x254x167 | 167.10 | 289.10 | 265.20 | 19.20 | 31.70 |
| 305x305x97 | 96.90 | 307.90 | 305.30 | 9.90 | 15.40 |
| 305x305x118 | 117.90 | 314.50 | 307.40 | 12.00 | 18.70 |
| 305x305x137 | 136.90 | 320.50 | 309.20 | 13.80 | 21.70 |
| 305x305x158 | 158.10 | 327.10 | 311.20 | 15.80 | 25.00 |
| 305x305x198 | 198.10 | 339.90 | 314.50 | 19.10 | 31.40 |
| 305x305x240 | 240.00 | 352.50 | 318.40 | 23.00 | 37.70 |
| 305x305x283 | 282.90 | 365.30 | 322.20 | 26.80 | 44.10 |
| 356x368x129 | 129.00 | 355.60 | 368.60 | 10.40 | 17.50 |
| 356x368x153 | 152.90 | 362.00 | 370.50 | 12.30 | 20.70 |
| 356x368x177 | 177.00 | 368.20 | 372.60 | 14.40 | 23.80 |
| 356x368x202 | 201.90 | 374.60 | 374.70 | 16.50 | 27.00 |
| 356x406x235 | 235.10 | 381.00 | 394.80 | 18.40 | 30.20 |
| 356x406x287 | 287.10 | 393.60 | 399.00 | 22.60 | 36.50 |
| 356x406x340 | 339.90 | 406.40 | 403.00 | 26.60 | 42.90 |
| 356x406x393 | 393.00 | 419.00 | 407.00 | 30.60 | 49.20 |
| 356x406x467 | 467.00 | 436.60 | 412.20 | 35.80 | 58.00 |
| 356x406x551 | 551.00 | 455.60 | 418.50 | 42.10 | 67.50 |
| 356x406x634 | 633.90 | 474.60 | 424.00 | 47.60 | 77.00 |
Universal Beams (UB)
Studley Special Steels offer a wide range of Universal Columns (UC). In particular, we specialise in high yield steel
columns for use in low temperature environments. Low temperature impact testing is available with lengths from 6
metres to 20 metres as standard.
Standards/Grades:
- EN 10025 S275
- EN 10025 S355
Note: The suffix 'UC' refers to UK steel columns – for continental columns (also referred to as H Sections) please click here.
Please refer to the sizes/specification table below
| Metric Dimensions | kg/m | Section Depth mm | Section Width mm | Web Thickness mm | Flange Thickness mm |
|---|---|---|---|---|---|
| 127x76x13 | 13.00 | 127.00 | 76.00 | 4.00 | 7.60 |
| 152x89x16 | 16.00 | 152.40 | 88.70 | 4.50 | 7.70 |
| 178x102x19 | 19.00 | 177.80 | 101.20 | 4.80 | 7.90 |
| 203x102x23 | 23.10 | 203.20 | 101.80 | 5.40 | 9.30 |
| 203x133x25 | 25.10 | 203.20 | 133.20 | 5.70 | 7.80 |
| 203x133x30 | 30.00 | 206.80 | 133.90 | 6.40 | 9.60 |
| 254x102x22 | 22.00 | 254.00 | 101.60 | 5.70 | 6.80 |
| 254x102x25 | 25.20 | 257.20 | 101.90 | 6.00 | 8.40 |
| 254x102x28 | 28.30 | 260.40 | 102.20 | 6.30 | 10.00 |
| 254x146x31 | 31.10 | 251.40 | 146.10 | 6.00 | 8.60 |
| 254x146x37 | 37.00 | 256.00 | 146.40 | 6.30 | 10.90 |
| 254x146x43 | 43.00 | 259.60 | 147.30 | 7.20 | 12.70 |
| 305x102x25 | 24.80 | 305.10 | 101.60 | 5.80 | 7.00 |
| 305x102x28 | 28.20 | 308.70 | 101.80 | 6.00 | 8.80 |
| 305x102x33 | 32.80 | 312.70 | 102.40 | 6.60 | 10.80 |
| 305x127x37 | 37.00 | 304.40 | 123.40 | 7.10 | 10.70 |
| 305x127x42 | 41.90 | 307.20 | 124.30 | 8.00 | 12.10 |
| 305x127x48 | 48.10 | 311.00 | 125.30 | 9.00 | 14.00 |
| 305x165x40 | 40.30 | 303.40 | 165.00 | 6.00 | 10.20 |
| 305x165x46 | 46.10 | 306.60 | 165.70 | 6.70 | 11.80 |
| 305x165x54 | 54.00 | 310.40 | 166.90 | 7.90 | 13.70 |
| 356x127x33 | 33.10 | 349.00 | 125.40 | 6.00 | 8.50 |
| 356x127x39 | 39.10 | 353.40 | 126.00 | 6.60 | 10.70 |
| 356x171x45 | 45.00 | 351.40 | 171.10 | 7.00 | 9.70 |
| 356x171x51 | 51.00 | 355.00 | 171.50 | 7.40 | 11.50 |
| 356x171x57 | 57.00 | 358.00 | 172.20 | 8.10 | 13.00 |
| 356x171x67 | 67.10 | 363.40 | 173.20 | 9.10 | 15.70 |
| 406x140x39 | 39.00 | 398.00 | 141.80 | 6.40 | 8.60 |
| 406x140x46 | 46.00 | 403.20 | 142.20 | 6.80 | 11.20 |
| 406x140x53* | 53.30 | 406.60 | 143.30 | 7.90 | 12.90 |
| 406x178x54 | 54.10 | 402.60 | 177.70 | 7.70 | 10.90 |
| 406x178x60 | 60.10 | 406.40 | 177.90 | 7.90 | 12.80 |
| 406x178x67 | 67.10 | 409.40 | 178.80 | 8.80 | 14.30 |
| 406x178x74 | 74.20 | 412.80 | 179.50 | 9.50 | 16.00 |
| 406x178x85* | 85.30 | 417.20 | 181.90 | 10.90 | 18.20 |
| 457x152x52 | 52.30 | 449.80 | 152.40 | 7.60 | 10.90 |
| 457x152x60 | 59.80 | 454.60 | 152.90 | 8.10 | 13.30 |
| 457x152x67 | 67.20 | 458.00 | 153.80 | 9.00 | 15.00 |
| 457x152x74 | 74.20 | 462.00 | 154.40 | 9.60 | 17.00 |
| 457x152x82 | 82.10 | 465.80 | 155.30 | 10.50 | 18.90 |
| 457x191x67 | 67.10 | 453.40 | 189.90 | 8.50 | 12.70 |
| 457x191x74 | 74.30 | 457.00 | 190.40 | 9.00 | 14.50 |
| 457x191x82 | 82.00 | 460.00 | 191.30 | 9.90 | 16.00 |
| 457x191x89 | 89.30 | 463.40 | 191.90 | 10.50 | 17.70 |
| 457x191x98 | 98.30 | 467.20 | 192.80 | 11.40 | 19.60 |
| 457x191x106* | 105.80 | 469.20 | 194.00 | 12.60 | 20.60 |
| 457x191x133* | 133.30 | 480.60 | 196.70 | 15.30 | 26.30 |
| 457x191x161* | 161.40 | 492.00 | 199.40 | 18.00 | 32.00 |
| 533x165x66* | 65.70 | 524.70 | 165.10 | 8.90 | 11.40 |
| 533x165x74* | 74.70 | 529.10 | 165.90 | 9.70 | 13.60 |
| 533x165x85* | 84.80 | 534.90 | 166.50 | 10.30 | 16.50 |
| 533x210x82 | 82.20 | 528.30 | 208.80 | 9.60 | 13.20 |
| 533x210x92 | 92.10 | 533.10 | 209.30 | 10.10 | 15.60 |
| 533x210x101 | 101.00 | 536.70 | 210.00 | 10.80 | 17.40 |
| 533x210x109 | 109.00 | 539.50 | 210.80 | 11.60 | 18.80 |
| 533x210x122 | 122.00 | 544.50 | 211.90 | 12.70 | 21.30 |
| 533x210x138* | 138.30 | 549.10 | 213.90 | 14.70 | 23.60 |
| 533x312x150* | 150.60 | 542.50 | 312.00 | 12.70 | 20.30 |
| 533x312x182* | 181.50 | 550.70 | 314.50 | 15.20 | 24.40 |
| 533x312x219* | 218.80 | 560.30 | 317.40 | 18.30 | 29.20 |
| 533x312x272* | 273.30 | 577.10 | 320.20 | 21.10 | 37.60 |
| 610x178x82* | 81.80 | 598.60 | 177.90 | 10.00 | 12.80 |
| 610x178x92* | 92.20 | 603.00 | 178.80 | 10.90 | 15.00 |
| 610x178x100* | 100.30 | 607.40 | 179.20 | 11.30 | 17.20 |
| 610x229x101 | 101.20 | 602.60 | 227.60 | 10.50 | 14.80 |
| 610x229x113 | 113.00 | 607.60 | 228.20 | 11.10 | 17.30 |
| 610x229x125 | 125.10 | 612.20 | 229.00 | 11.90 | 19.60 |
| 610x229x140 | 139.90 | 617.20 | 230.20 | 13.10 | 22.10 |
| 610x305x149 | 149.20 | 612.40 | 304.80 | 11.80 | 19.70 |
| 610x305x179 | 179.00 | 620.20 | 307.10 | 14.10 | 23.60 |
| 610x305x238 | 238.10 | 635.80 | 311.40 | 18.40 | 31.40 |
| 686x254x125 | 125.20 | 677.90 | 253.00 | 11.70 | 16.20 |
| 686x254x140 | 140.10 | 683.50 | 253.70 | 12.40 | 19.00 |
| 686x254x152 | 152.40 | 687.50 | 254.50 | 13.20 | 21.00 |
| 686x254x170 | 170.20 | 692.90 | 255.80 | 14.50 | 23.70 |
| 762x267x134 | 133.90 | 750.00 | 264.40 | 12.00 | 15.50 |
| 762x267x147 | 146.90 | 754.00 | 265.20 | 12.80 | 17.50 |
| 762x267x173 | 173.00 | 762.20 | 266.70 | 14.30 | 21.60 |
| 762x267x197 | 196.80 | 769.80 | 268.00 | 15.60 | 25.40 |
| 838x292x176 | 175.90 | 834.90 | 291.70 | 14.00 | 18.80 |
| 838x292x194 | 193.80 | 840.70 | 292.40 | 14.70 | 21.70 |
| 838x292x226 | 226.50 | 850.90 | 293.80 | 16.10 | 26.80 |
| 914x305x201 | 200.90 | 903.00 | 303.30 | 15.10 | 20.20 |
| 914x305x224 | 224.20 | 910.40 | 304.10 | 15.90 | 23.90 |
| 914x305x253 | 253.40 | 918.40 | 305.50 | 17.30 | 27.90 |
| 914x305x289 | 289.10 | 926.60 | 307.70 | 19.50 | 32.00 |
| 914x419x343 | 343.30 | 911.80 | 418.50 | 19.40 | 32.00 |
| 914x419x388 | 388.00 | 921.00 | 420.50 | 21.40 | 36.60 |
| 1016x305x222 | 222.00 | 970.30 | 300.00 | 16.00 | 21.10 |
| 1016x305x249 | 248.70 | 980.10 | 300.00 | 16.50 | 26.00 |
| 1016x305x272 | 272.30 | 990.10 | 300.00 | 16.50 | 31.00 |
| 1016x305x314 | 314.30 | 999.90 | 300.00 | 19.10 | 35.90 |
| 1016x305x349 | 349.40 | 1008.10 | 302.00 | 21.10 | 40.00 |
| 1016x305x393 | 392.70 | 1015.90 | 303.00 | 24.40 | 43.90 |
| 1016x305x437 | 437.00 | 1026.10 | 305.40 | 26.90 | 49.00 |
To discuss your requirements or find out more please call our experienced team on +44 (0)1527 830490 or complete the contact form below.
